Box Packing Mahcine Pulper / Hydrapulper For Recycled Wastepaper / Egg Tray
High consistency hydra pulpers are used in the production line of wasted paper de-inking in pulp-making industry. They can pulp wasted paper promptly, thick liquid board, and at same time.
It can protect the fiber original character. Once adding the chemical, it can separate the ink particle and impurity to out from the fiber to get the thick liquid with high white degree.
Technical specification
| Model | ZGS1 | ZGS2 | ZGS3 | ZGS5 | ZGS8 | ZGS10 | ZGS15 | ZGS20 | ZGS25 | ZGS30 |
| Nominal volume (m3) | 1 | 2 | 3 | 5 | 8 | 10 | 15 | 20 | 25 | 30 |
Capacity (t/d) (22.5hours/day) | 3-4 | 6-8 | 9-12 | 15-20 | 24-32 | 30-45 | 40-80 | 50-90 | 100-120 | 110-150 |
| Consistency (%) | 10+2 | 10+2 | 10+2 | 10+2 | 10+2 | 10+2 | 10+2 | 10+2 | 10+2 | 10+2 |
| Tank diameter (mm) | 1200 | 1550 | 1800 | 2200 | 2500 | 2800 | 3100 | 3350 | 3700 | 4000 |
| Power of motor (kw) | 6-22 | 6-37 | 6-55 | 6-75 | 6-90 | 6-110 | 6-160 | 6-250 | 6-315 | 6-4 |
Application
1. Waste paper recycling machine
2.Used for breaking waste paper
3. Waste paper de-inking line
Feature & benefit
1. Vertical impeller.
2. Stock in uniformed and constant quality
3. High consistency ( 10-14%)
About Us
Since 1989 Qinyang City Haiyang Papermaking Machinery Co., Ltd has
been established who is specialist in manufacturing a wide range of
Paper Machines for Kraft, Test liner, Fluting paper, Corrugate,
Writing & Printing, Newspaper, Duplex Board. We have more than 30
years expertise lies in applying state of the art technology to
provide cost effective custom designed solutions to suit their
varied requirements.
This company has processing and testing equipment like Longmen CNC machine, planer milling machine, vertical boring machine, automatic continuous welding machine, high speed dynamic balance correction machine, assembly test table etc. With sophisticated processing machinery and professional technical personnel, this company can produce super paper machine equipment.
The main series of the products are tissue paper machine;kraft
paper/testliner /fluting paper machine;writing paper machine and
special paper machine,etc. This company provides customers high
efficiency and practical paper making production line with low
carbon environmental protection thought. At present, our products
have been sold to more than twenty provinces, cities and autonomous
regions in domestic region and exported to Vietnam,Egypt,
Bangladesh,Malaysia,Pakistan,Iran and other countries.
Packaging Details
1. Seaworthy export packing
2. Standard export packing
3. As per customers' requirement
FAQ
01. We are a manufacturer and we have import and export rights.
02. We produce wonderful environmental protection machines and solutions, pulp and paper making machines and solutions as well as tissue paper converting machinery and solutions,
03. Our main manufacturing facility which spans nearly 30,000m2.
04. We have achieved a total of 32 patents over the past few years.
05. Each year the output value of our products can reach up to 150
million RMB, to domestic and overseas.
06. We are in very close proximity to a very famous port city –
Qingdao in northern China, and this location provides us with a
plethora of logistics advantages, including: easy and cost
effective transport by both air and sea, also.

|
